| Brand Name: | Beishun |
| Model Number: | XK-560 |
| MOQ: | 1set |
| Price: | USD 10000-90000 Set |
| Payment Terms: | TT，L/C |
Roller Mixer Open Mixing Mill Machine With Stock Blender For Rubber Compounding
What is Rubber Mixing Mill Machine?
The two roll Rubber Mixing Mill Machine is a machine used to process natural rubber into various compounds. Two horizontally opposed stainless steel rolls rotate in opposite directions towards each other at different speeds to mix the rubber and ingredients used to create the rubber compounds.
Application
The rubber mixing mill machine is widely used in the milling process of rubbers and rubber products. The rubber mixing mill machine is mainly used for mixing raw rubber, rubber, thermoplastic or ethylene-vinyl acetate with chemicals, heating, pressing, breaking, plasticizing and mixing. The final material can be transported to rubber calender, batch off cooler, rubber extruder, rubber vulcanizing press or other processing machines for the heating, pressing, breaking, plasticizing and mixing of rubber or plastic products.
Machine specification of Rubber Mixing Mill Machine
| XK-160 | φ160x320 | 8.95 | 1:1.37 | 5.5 | 1500x750x1500 |
| XK-230(AZ) | φ230x600 | 10.21 | 1:1.19 | 15 | 2800×1200×1120 |
| XK-250(AZ) | φ250x620 | 14.1 | 1:1.17 | 18.5 | 3400×1500×1650 |
| XK-300 | φ300x750 | 15.1 | 1:1.25 | 22 | 3500×1600×1700 |
| XK-360 | φ360x900 | 16.25 | 1:1.25 | 30 | 3780×1850×1750 |
| XK-400 | φ400x1000 | 18.65 | 1:1.27 | 37 | 4350×1850×1785 |
| XK-450 | φ450x1200 | 24.26 | 1:1.27 | 55 | 5200×2380×1840 |
| XK-560(AZ) |
φ560x1530 φ510x1530 |
27.72 | 1:1.2 | 90 | 5845×2284×1978 |
| XK-550B | φ550x1500 | 27.94 | 1:1.22 | 110 | 5870×2475×2045 |
| XK-610 | φ610x2000 | 28.42 | 1:1.17 | 160 | 7070×2290×1840 |
| XK-660 | φ660x2130 | 28.6 | 1:1.24 | 245 | 7465×3662×2080 |
| XK-710 | φ710x2200 | 30 | 1:1.09 | 280 | 7500×3500×1800 |
Product description
1. The Two Roll Mixing Mill For Compounding Rubber occupies a small area and the overall length is only 3/4 that of normal rubber mixing mills.
2. The rubber blending mixing mill is equipped with a hardened gear reducer. Gears are all treated by carburizing and quenching techniques. The gear surface is carefully grinded as well. Such processes increase machining accuracy, wear-resistance and reduce noise.
3. The friction gears of the rubber mixing mil sit between the roller and reducer to avoid cooling water and condensate water from entering into lubricating oil trough.
4. The rubber mixing mill is equipped with a stock blender that is usually only used in rubber kneading machines.The advantages of this include a decrease in machine labor intensity and it reduces the mixing time and working efficiency. The hydraulic gluing process also maximizes operation stability.
5. Adoption of a rolling bearing for the roller helps to minimize friction. A labyrinth seal, instead of an oil seal is used to prevent the inconvenience of replacing the framework oil seal while maintaining.
FAQ
1. Delivery time of the Batch Off Rubber Cooling Machine?
This is specially designed machine according to your specific requirement.
From engineer designing to production completion, it needs about 35 to 45 days.
2. What does your factory do regarding quality control?
We pay much more importance to quality control from the very beginning to the end of production.
Every machine will be fully assembled and carefully tested before shipment.
3. What's the machine quality guarantee?
Quality guarantee time is two year.We choose world famous brand components to keep our machine in perfect working condition.
4. Are you able to give installation and commissioning overseas? How long time will it take?
Yes, we can supply overseas service and technical support but customer needs to pay for the cost of the installation.
Small machine usually takes within 3~5 days.
Big plant usually takes about 30 days.
5.How can I trust you to deliver the right machine as I ordered?
We will absolutely deliver a good quality machine as we discussed and confirmed in the order. At the same time, we regularly send the production schedule and machine photos during the production process.
The core of our company culture is innovation,quality,integrity and efficiency. Also we have had many good cooperation with world famous rubber production manufacturers. If you come to our factory, we can show you're the user around us.
6.How can we go to your side?
We are located in Qingdao City, Shandong province, China. The name of airport is Qingdao liuting airport. We will pick up you at the airport.
MACHINE LIST
Our company specially manufacturring rubber mixing mill, rubber vulcanizing press, rubber kneader, batch off rubber cooling machine and tire recycling line.
|
